UN ANALYSEUR d’eau de PISCINE CONNECTÉ

//------------------------------------------------------
//                https://gammatroniques.fr/
//                    Code pHMetre Piscine
//                 08/2021 - by GammaTroniques
//------------------------------------------------------
esphome:
  name: esp_piscine
  platform: ESP8266
  board: d1_mini

wifi:
  ssid: "VotreWifi"
  password: "VotrePassword"
  ap:
    ssid: "Wifi-Piscine"
    password: "Wifi-PiscinePh"

captive_portal:
logger:
api:
ota:

i2c:
  sda: D2
  scl: D1
  scan: True

ads1115:
  - address: 0x48

dallas:
  - pin: D7
    update_interval: 10s

sensor:

  - platform: ads1115     #pH en volt
    multiplexer: 'A0_GND'
    gain: 6.144
    id: "phvolt"
    unit_of_measurement: ""
    icon: "mdi:water"
    update_interval: 2s
    accuracy_decimals: 3


  - platform: ads1115     #pH converti en pH
    multiplexer: 'A0_GND'
    gain: 6.144
    name: "Ph Piscine"
    id: "ph"
    filters:
       - calibrate_linear:
           - 3.027 -> 4.01
           - 2.542 -> 6.86
           - 2.179 -> 9.18
    unit_of_measurement: ""
    icon: "mdi:water"
    update_interval: 2s
    accuracy_decimals: 3



  - platform: ads1115     #tension de la batterie
    multiplexer: 'A3_GND'
    gain: 6.144
    name: "Tension Batterie Piscine"
    unit_of_measurement: "V"
    update_interval: 60s
    accuracy_decimals: 3

  - platform: dallas     #sonde de Température
    address: 0x5B021460A924FF28
    id: "temp"
    name: "Température Piscine"
    accuracy_decimals: 3

binary_sensor:
  - platform: gpio     #le Bouton
    pin: D6
    id: button
    on_press:
      then:
          - globals.set:
              id: screenOn
              value: 'true'

globals:
 - id: screenOn
   type: bool
   restore_value: no
   initial_value: 'true'

time:
  - platform: sntp
    on_time:
      # Every 5 minutes
      - seconds: 0
        minutes: /5
        then:
          - globals.set:
              id: screenOn
              value: 'false'

font:
  - file: "fonts/Product-Sans.ttf"
    id: product_sans_20
    size: 20

display:
  - platform: ssd1306_i2c
    model: "SSD1306 128x64"
    address: 0x3C
    lambda: |-
      if(id(screenOn)){
        it.printf(0, 0, id(product_sans_20), "%.1f°C", id(temp).state); //affichage de la Température
        it.printf(0, 20, id(product_sans_20), "pH: %.1f V", id(phvolt).state); //affichage du ph en volt
        it.printf(0, 20, id(product_sans_20), "pH: %.1f", id(ph).state); //affichage du ph
      }else{

      }
